Overview / Features
This product is a I/O module that adds the interface, which counts input pulse signals from external devices, to the CPU Unit of the CONPROSYS nano series.
It has one channel of 32-bit up/down counters, allowing external devices such as a rotary encoder and a linear scale to be connected.
Examples are given for “detecting a position of the table of a machine tool” and “detecting a change in weight”.
-
Count two-phase signals
- This product can count two-phase and single-phase signals including encoders, and linear scales. It is equipped with one 32-bit up/down counter.
-
Opto-coupler isolated input
- Opto-coupler isolated input of 500 kHz response frequency within.
-
Interrupt, Output signal
- Generate an interrupt or output one-pulse signal when the count data of the channel matches a specified value.
-
Digital filter to prevent input signals from carrying noise or a chattering
- This product has a digital filter to prevent input signals from carrying noise or a chattering.
All input terminals can be added a digital filter, and the setting can be performed by software.
- This product has a digital filter to prevent input signals from carrying noise or a chattering.
-
Output circuit includes zener diode for surge voltage protection
- Zener diode is connected to the output circuit to protect against surge voltages. The rated output is 35VDC, 50mA to the maximum per channel.
-
Adaptable to a wide range of temperature between -20 and 60°C
- The product is capable of operating in the temperature between -20 and 60°C. It can be installed in the various environments.
Add-on module
Bus Specification | CONPROSYS nano slot |
---|---|
Size | CONPROSYS nano 1U |
Used Connector | 3.81mm-pitch 10-pin 2-piece terminal block |
Counter
Number of Channels | 1-ch |
---|---|
Counting System | 32-bit Up/Down count |
Response speed | 500KHz |
