UST200-83H-FL

Features

• CE, FCC certified; ISO 7637-2 compliant
• Intel® Atom® x5-E3930 processor
• Extreme cost-effective with fanless and cableless design
• Wide operating temperature range from -40°C to +70°C
• Supports 12 & 24 VDC typical in-vehicle power input
• Smart Ignition for power on/off schedule, vehicle battery protection and different power mode
• 1 COM or CAN, 2 USB, 2 GbE LAN
• 8-bit programmable DIO for IoT gateway applications
• Supports SocketCAN
• AMS.AXView intelligent remote monitoring

Introduction

The UST200-83H-FL is powered by the low-power consumption Intel® Atom™ x5-E3930 processor. It is certified with CE and FCC and is in compliance with ISO 7637-2. With the function of the Smart Ignition power control, the rugged embedded system can arrange a power on/off schedule to protect the vehicle battery from unstable voltage. This high-performance IoT gateway delivers an excellent price-performance ratio for in-vehicle applications.  Thanks to its ruggedized design for harsh environments, the UST200-83H-FL is able to operate under a wide temperature range from -40°C to +70°C and vibration of up to 3 Grms. This IoT gateway supports both wall mounting and DIN-rail mounting. Its ultra-lightweight and compact design is ideal for space constraint environments.
