MMB501

Features

• LGA1151 socket 7th/6th gen Intel® Core™ i7/i5/i3, Pentium® & Celeron® processor (Kaby Lake/Skylake)
• Four 288-pin DDR4-2133/2400 DIMM for up to 64GB of memory
• DisplayPort, VGA, DVI-D and HDMI with triple-view supported
• 6 SATA-600 with RAID 0/1/5/10
• 6 USB 3.0 and 5 USB 2.0

Introduction

The MMB501 is powered by the LGA1151 socket 7th/6th generation Intel® Core™ i7/i5/i3, Pentium® and Celeron® processors (formally codename: Kaby Lake/Skylake) with Intel® Q170 chipset. The MMB501 supports four high bandwidth 288-pin DDR4-2133/2400 with a memory capacity up to 64GB. The industrial-grade micro ATX motherboard is expandable with one PCIe x16 slot, two PCIe x4 slots, one PCI slot and one full-size PCI Express Mini Card slot. Moreover, the embedded board supports triple-display via DisplayPort, HDMI, DVI-D and VGA interfaces. Furthermore, this outstanding multi-function embedded motherboard is integrated with the Intel® HD Graphics 530/510 to deliver stunning UHD 4K resolution and fast 3-D and video playback for graphics-intensive applications. To meet the distinct needs from users, there are six SATA-600 with RAID 0/1/5/10, six USB 3.0, five USB 2.0, four RS-232 ports, two RS-232/422/485 ports, one DisplayPort, one DVI-D, one HDMI and one VGA, as well as has two Gigabit Ethernet ports with Intel® i219LM and Intel® i211AT controllers. To ensure stable and reliable operation, the high-performance Intel® Core™-based industrial micro ATX motherboard supports a watchdog timer and hardware monitoring features. Furthermore, this new embedded board runs well with Windows® 7, and Windows® 10 operating systems.
