Overview / Features
The ED3541 Ethernet extender allows the extension of IP services beyond normal Ethernet distance limitations without changing cables, breaking the 100-meter Ethernet barrier.
The ED3541’s hardened design features high shock and vibration, electrical noise immunity, a wide operating temperature range from -40 to 75°C, and ruggedized aluminum housing. The ED3541 is the ideal Ethernet extender for environments where connectivity is crucial.
Interface
- Ethernet Port
- Port: One RJ-45 port
- Speed: 10/100Mbps
- Distance: 100 meters (328ft.)
- Cable: 10BASE-T: UTP Cat. 3, 4, 5 (2-pair wire); 100BASE-TX: UTP Cat. 5 (4-pair wire)
- Ethernet Extender Port
- Port: One RJ-11/Terminal Block port
- Speed: Up to 100Mbps
- Distance: 2200 meters (7,217ft.)
- Cable: Telephone wire 24AWG (0.5mm diameter, 1-pair wire) or larger
- DIP Switch
- DIP 1 Site: Auto/Loc
- DIP 2 LDR: On/Off
- LED Indicators
- Per Unit: Power 1, Power 2
- Per 10/100TX Port: Link/Activity, full-duplex
- Line Speed: 100/80/60/40/20Mbps and link below 20Mbps
| Distance (m) | Data rate (Mbps) |
| 200 | 100 |
| 400 | 80 |
| 600 | 60 |
| 800 | 40 |
| … | … |
| 2200 | 1 |
All speed selections are Symmetrical on the DSL and Full-duplex on the Ethernet.
The data rate will vary according to the line quality.
Technology
- Standards
- IEEE 802.3 10BASE-T
- IEEE 802.3u 100BASE-TX
- IEEE 802.3x full duplex and flow control
- Processing Type
- Half-duplex back-pressure and IEEE 802.3x full-duplex flow control
- Auto-negotiation
- Auto MDI/MDIX
Power
- Input
- 12-48VDC Redundant (Terminal Block)
- Power Consumption
- 4.56W max. 0.38A@12VDC, 0.07A@48VDC
- Protection
- Over Current Protection
- Reverse Polarity Protection
Physical
- Casing Material
- Aluminum
- Dimensions
- 42 x 90 x 100mm (W x D x H)
1.65” x 3.54” x 3.94″
- 42 x 90 x 100mm (W x D x H)
- Weight
- 0.41kg (0.9lbs)
- Installation Type
- DIN-rail mounting (Top hat type 35mm)
Environmental
- Operating Temp.
- -40 to 75°C (-40 to 167°F)
- Storage Temp.
- -45 to 85°C (-49 to 185°F)
- Relative Humidity
- 5% to 95% (non-condensing)
Regulatory
- ISO
- Manufactured in ISO-9001 facility
- EMI
- FCC Part 15B Class A
- VCCI Class A
- EN 61000-6-4
- EMS
- EN 61000-6-2
- EN 61000-4-2 (ESD)
- EN 61000-4-3 (Radiated RFI)
- EN 61000-4-4 (Burst)
- EN 61000-4-5 (Surge)
- EN 61000-4-6 (Induced RFI)
- EN 61000-4-8 (Magnetic field)
- Safety
- UL 61010
- EN 60950-1
- IEC 60950-1
- ISA 12.12.01
- Class 1, Division 2 group A, B, C & D for hazardous locations
- Vibration
- IEC 60068-2-6 Fc
- Shock
- IEC 60068-2-27 Ea
- Free Fall
- FED STD 101C Method 5007.1
Warranty
- Length
- Limited Lifetime
- Details
What’s Included
- Device
- Ethernet Extender
- Documentation
- Quick Install Guide
